Marantz SR9600 - Page 163

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P214 K353 00MHK121619F0 00MHK121619F0 TRS. KIT ! 2SA1216/2SC2922 PAIR FOR Q366/Q36
7
P214 Q366 ns
p
ns
p
TRS. ! 2SC2922 17A 200W PIAR WITH Q36
7
P214 Q367 ns
p
ns
p
TRS. ! 2SA1216 17A 200W PIAR WITH Q36
6
P214 Q151 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P214 Q153 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q154 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q155 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q156 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q157 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q158 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q159 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P214 Q160 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P214 Q168 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q251 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P214 Q253 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q254 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q255 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q256 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q257 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q258 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q259 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P214 Q260 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P214 Q268 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q351 00MHC10053090 00MHC10053090 IC NJM2068DD:MONO AN
A
P214 Q353 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q354 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q355 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q356 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q357 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 Q358 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q359 00MHT600131B0 00MHT600131B0 TRS. KTA1024 PNP TRANSISTOR RANK=Y
P214 Q360 00MHT800941B0 00MHT800941B0 TRS. KTC3206 NPN TRANSISTOR RANK=Y
P214 Q368 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=GR
P214 Q801 00MHC10062360 00MHC10062360 IC ! LM1085IT-5.0#NOPB
P214 Q802 00MHC10062360 00MHC10062360 IC ! LM1085IT-5.0#NOPB
P214 QN01 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN02 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN03 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN04 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRANSISTOR RANK=Y
P214 QN05 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN06 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P214 QN09 00MHC10009090 00MHC10009090 IC NJM2901 QUAD COMPARATOR
P214 QN10 00MHC10009090 00MHC10009090 IC NJM2901 QUAD COMPARATOR
P214 QN13 00MHC10009090 00MHC10009090 IC NJM2901 QUAD COMPARATOR
P214 QN14 00MHT334191Y0 00MHT334191Y0 TRS. ! C3419 Y 40V 0.8A PC=1.2W
(
5W
)
P214 QN15 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P214 QN16 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P214 QN19 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN20 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P214 QN23 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P214 R154 ns
p
00MGD05180160 RES. 18 OHM +- 5% 1/6
W
P214 R155 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P214 R156 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P214 R157 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P214 R158 00MNK05121020 00MNK05121020 METAL RES. 120 OHM +-5% 2W ERG2SJ121E
P214 R159 00MNK05151020 00MNK05151020 METAL RES. 150 OHM +-5% 2W ERG2SJ151E
P214 R160 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
P214 R161 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P214 R162 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P214 R165 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P214 R166 ns
p
00MGD05330160 RES. 33 OHM +- 5% 1/6
W
P214 R167 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P214 R168 00MNB51514240 00MNB51514240 RES. LT 150 OHM 1/6W J 2400PPM
P214 R169 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P214 R170 ns
p
00MGD05334160 RES. 330K OHM +- 5% 1/6
W
P214 R171 ns
p
00MGD05682160 RES. 6.8K OHM +- 5% 1/6
W
P214 R172 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
221
