Marantz SR9600 - Page 167

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P314 R240 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P314 R338 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P314 R340 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P314 R438 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P314 R440 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P314 R831 ns
p
00MGD05153160 RES. 15K OHM +- 5% 1/6
W
P314 R832 ns
p
00MGD05153160 RES. 15K OHM +- 5% 1/6
W
P314 R833 ns
p
00MGD05153160 RES. 15K OHM +- 5% 1/6
W
P314 R834 ns
p
00MGD05153160 RES. 15K OHM +- 5% 1/6
W
P314 R835 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 R836 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P314 R837 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
P314 R841 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P314 R842 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P314 R843 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 R844 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
P314 R845 ns
p
00MGD05224160 RES. 220K OHM +- 5% 1/6
W
P314 R846 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P314 R851 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P314 R852 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 R855 00MNK05471010 00MNK05471010 METAL RES. 470 OHM +-5% 1W ERG1SJ471E
P314 R856 00MNK05471010 00MNK05471010 METAL RES. 470 OHM +-5% 1W ERG1SJ471E
P314 RN75 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P314 RN76 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 RN77 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P314 RN78 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 RN79 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P314 RN80 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 RN88 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P314 RN89 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P314 RN91 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
P314 RN92 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
P314 RN97 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P314 RN98 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P314 RN99 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
P314 RPA1 00MNK05471010 00MNK05471010 METAL RES. 470 OHM +-5% 1W ERG1SJ471E
P314 RPA2 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
P314 RPA3 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
SPEAKER2 PWB
(
00MWA12AJ302-
)
P324 C159 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P324 C169 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APS
V
P324 C259 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P324 C269 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APS
V
P324 C359 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P324 C369 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APS
V
P324 DN23 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P324 DN24 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P324 J843 00MYT01060030 00MYT01060030 TERMINAL SCREW TERMINAL YKD31-0570 6P
P324 LN13 00MLY2024031
0
00MLY2024031
0
RELAY VB 24MBU-510 5A/240VAC
P324 LN14 00MLY2024031
0
00MLY2024031
0
RELAY VB 24MBU-510 5A/240VAC
P324 QN34 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P324 R188 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 R190 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 R288 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 R290 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 R388 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 R390 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1W ERG1SJ-E
P324 RN81 ns
p
00MGD05332160 RES. 3.3K OHM +- 5% 1/6
W
P324 RN82 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P324 RN93 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
P324 RN94 00MNK05331010 00MNK05331010 METAL RES. 330 OHM +-5% 1W ERG1SJ-E
PRIMARY PWB
(
00MWA12AJ303-
)
P334 CB01 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P334 CB02 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P334 DB01 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P334 DB02 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P334 FB01
/
F N ns
p
00MFS11200440 FUSE # 12A 250V UL,CSA,MITI NO.31
4
225
