Marantz SR9600 - Page 168

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P334 FB01
/
N1B 00MFS10630850 00MFS10630850 FUSE # 6.3 A 250V BS LISTED
P334 FB01
/
N1G 00MFS10630850 00MFS10630850 FUSE # 6.3 A 250V BS LISTED
P334 FB01
/
N1S 00MFS10630850 00MFS10630850 FUSE # 6.3 A 250V BS LISTED
P334 FB01
/
U1B ns
p
00MFS11200440 FUSE # 12A 250V UL,CSA,MITI NO.31
4
P334 FB01
/
U1G ns
p
00MFS11200440 FUSE # 12A 250V UL,CSA,MITI NO.31
4
P334 FB02
/
F N ns
p
00MFS20315200 FUSE # FUSE 3.15A 250V SEMKO VDE
P334 FB02
/
N1B 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(T
P334 FB02
/
N1G 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(T
P334 FB02
/
N1S 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(T
P334 FB02
/
U1B ns
p
00MFS20315200 FUSE # FUSE 3.15A 250V SEMKO VDE
P334 FB02
/
U1G ns
p
00MFS20315200 FUSE # FUSE 3.15A 250V SEMKO VDE
P334 JB05
/
N1B 00MYJ0400164
0
00MYJ0400164
0
JACK ! AC SOCKET YKE31-0090 SEMKO
P334 JB05
/
N1G 00MYJ0400164
0
00MYJ0400164
0
JACK ! AC SOCKET YKE31-0090 SEMKO
P334 JB05
/
N1S 00MYJ0400164
0
00MYJ0400164
0
JACK ! AC SOCKET YKE31-0090 SEMKO
P334 JB06
/
F N ns
p
00MYJ0400204
0
JACK ! 2P AC OUTLET
(
CCT1304-0212
)
P334 JB06
/
U1B ns
p
00MYJ0400204
0
JACK ! 2P AC OUTLET
(
CCT1304-0212
)
P334 JB06
/
U1G ns
p
00MYJ0400204
0
JACK ! 2P AC OUTLET
(
CCT1304-0212
)
P334 LB01 00MLY1005014
0
00MLY1005014
0
RELAY ! VS-5MB-NR-SM2
P334 LB02 00MLY1005013
0
00MLY1005013
0
RELAY ! SDT-S-105LMR
P334 QB01 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
P334 QB02 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
P334 QB03 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P334 QB04 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P334 RB01 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P334 RB02 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
P334 RB03 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P334 RB04 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
P334 RB05 00MNQ15022070 00MNQ15022070 ROTOR RES. ! 2.2 OHM 7W W/TEMP.FUSE
P334 RB06 00MNQ15022070 00MNQ15022070 ROTOR RES. ! 2.2 OHM 7W W/TEMP.FUSE
CS DSP PWB
(
00MWI12AJ901-
)
P514 C501 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
P514 C502 00MEY22505020 00MEY22505020 ELECT CAP. 2.2UF/ 50V
P514 C503 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
P514 C504 ns
p
00MDK96102300 CER. CAP. 1000 PF +- 10 % B 50V GR3
6
P514 C505 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C506 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
P514 C507 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C508 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C509 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C510 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C511 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C512 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C513 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C514 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C515 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C516 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C517 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C518 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C519 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C520 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C521 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C522 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C523 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C524 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C525 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C526 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C527 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C528 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C529 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C530 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C531 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C532 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C533 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C534 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C535 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
P514 C536 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
P514 C537 00MEY10700620 00MEY10700620 ELECT CAP. 100UF/6.3V
