Marantz SR9600 - Page 172

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P514 CU65 ns
p
00MDK96102300 CER. CAP. 1000 PF +- 10 % B 50V GR3
6
P514 DA01 00MHZ21006000 00MHZ21006000 CHIP DIODE 1SS300,DAP202U UMT TYPE
P514 DA02 00MHZ21006000 00MHZ21006000 CHIP DIODE 1SS300,DAP202U UMT TYPE
P514 DA03 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
P514 DA04 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
P514 DU51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
P514 DU52 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
P514 J503 00MYJ0706139
0
00MYJ0706139
0
JACK IMSA-9852S-22Y902
P514 JA01 00MYT02041380 00MYT02041380 TERMINAL YKC21-4766N 1L4P FG AU
P514 JA02 00MYJ1500027
0
00MYJ1500027
0
OPT. CONN. TORXL141
(
F
)
P514 JA03 00MYJ1500027
0
00MYJ1500027
0
OPT. CONN. TORXL141
(
F
)
P514 JA04 00MYJ1500027
0
00MYJ1500027
0
OPT. CONN. TORXL141
(
F
)
P514 JA05 00MYJ1500027
0
00MYJ1500027
0
OPT. CONN. TORXL141
(
F
)
P514 JA08 00MYT02011750 00MYT02011750 TERMINAL YKC21-3479N 1L1P FG AU
P514 JA09 00MYJ1500022
0
00MYJ1500022
0
OPT. CONN. TOTX179L TOSLINK TRANSCEIVER
P514 JA53 00MYP07005640 00MYP07005640 PLUG IMSA-9851B-14Y902
P514 JA54 00MYP07005650 00MYP07005650 PLUG IMSA-9851B-22Y905
P514 L501 00MFC90020120 00MFC90020120 FERRITE CORE BK1608HM102-T FERRIT BEADS
P514 L502 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L503 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L504 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L505 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L506 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L507 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 L508 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
P514 LA02 00MFC90020120 00MFC90020120 FERRITE CORE BK1608HM102-T FERRIT BEADS
P514 LA31 00MLU15103010 00MLU15103010 CHIP INDUCTANCE NL252018 10UH
P514 Q501 00MHC10022880 00MHC10022880 IC CS495202-CQZ
P514 Q502 80M11AJ900101 80M11AJ900101 U-PRO
M29W800DT70N1 CS DSP FLASH
P514 Q503 00MHC12250990 00MHC12250990 IC W986416DH-7 -> W9864G6EH-7
(
PBFREE
)
P514 Q504 00MHC005805K0 00MHC005805K0 IC TC74VHC157F
T
P514 Q505 00MHC011905K0 00MHC011905K0 IC TC74VHC153FT
(
EL,K
)
P514 Q506 00MHC011905K0 00MHC011905K0 IC TC74VHC153FT
(
EL,K
)
P514 Q507 00MHC011905K0 00MHC011905K0 IC TC74VHC153FT
(
EL,K
)
P514 Q508 00MHC011905K0 00MHC011905K0 IC TC74VHC153FT
(
EL,K
)
P514 Q509 00MHC98818990 00MHC98818990 IC NCP1117STAT3 1.25-18.8V ADJ REG.800M
A
P514 Q510 00MHC98818990 00MHC98818990 IC NCP1117STAT3 1.25-18.8V ADJ REG.800M
A
P514 Q512 00MHY22010050 00MHY22010050 CHIP FET HN1K05FU 2SK2824 X 2
P514 QA01 00MHC009205K0 00MHC009205K0 IC TC74VHCU04FT
P514 QA02 00MHC009205K0 00MHC009205K0 IC TC74VHCU04FT
P514 QA03 00MHC007505K0 00MHC007505K0 IC TC74VHCT08AFT EL X4 2INPUT AND
P514 QA04 00MHC715100Z0 00MHC715100Z0 IC TC74HC151AF
P514 QA31 00MHC009405K0 00MHC009405K0 IC TC74VHC125F
T
P514 QA32 00MHC011005K0 00MHC011005K0 IC TC74LCX541FT
(
EL,K
)
P514 QA33 00MHC011005K0 00MHC011005K0 IC TC74LCX541FT
(
EL,K
)
P514 QA34 00MHC011005K0 00MHC011005K0 IC TC74LCX541FT
(
EL,K
)
P514 QA35 00MHC011005K0 00MHC011005K0 IC TC74LCX541FT
(
EL,K
)
P514 QA36 00MHC011005K0 00MHC011005K0 IC TC74LCX541FT
(
EL,K
)
P514 QK01 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK02 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK03 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK04 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK05 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK06 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK07 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK08 00MHC10172090 00MHC10172090 IC NJM2115M TE1
P514 QK09 00MHC10023880 00MHC10023880 IC CS5361-KSZ 2CH ADC 192KHZ 114DB
P514 QK10 00MHC10023880 00MHC10023880 IC CS5361-KSZ 2CH ADC 192KHZ 114DB
P514 QK11 00MHC10023880 00MHC10023880 IC CS5361-KSZ 2CH ADC 192KHZ 114DB
P514 QK12 00MHC10023880 00MHC10023880 IC CS5361-KSZ 2CH ADC 192KHZ 114DB
P514 QK14 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK15 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK16 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK17 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK18 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK19 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK20 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
230
