Marantz SR9600 - Page 173

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P514 QK21 00MHX342132A0 00MHX342132A0 CHIP TRS. 2SC4213
P514 QK22 00MBA10013050 00MBA10013050 TRS. RN2303
(
PNPX1
(
22K+22K
))
P514 QR01 00MHC10418030 00MHC10418030 IC LC89057W-VF4-E DAIO
P514 QR03 00MHC008205K0 00MHC008205K0 IC TC74VHC08FT
P514 QU01 80M11AJ900201 80M11AJ900201 U-PRO
HD64F2505FC26DV SUB CPU
P514 QU02 00MHX115881A0 00MHX115881A0 CHIP TRS. 2SA1588
(
Y
)
P514 QU03 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
P514 QU04 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT TYPE
P514 QU05 00MHC011405K0 00MHC011405K0 IC TC74VHCT00AFT
(
EL,K
)
P514 QU06 00MHC008205K0 00MHC008205K0 IC TC74VHC08FT
P514 QU51 00MHC008205K0 00MHC008205K0 IC TC74VHC08FT
P514 QU52 00MHC007505K0 00MHC007505K0 IC TC74VHCT08AFT EL X4 2INPUT AND
P514 QU53 00MHC009405K0 00MHC009405K0 IC TC74VHC125F
T
P514 QU54 00MHC011705K0 00MHC011705K0 IC TC74LCX00FT
(
EL.K
)
P514 R501 ns
p
00MNN05181610 CHIP RES. 180 OHM +- 5% 1/16
W
P514 R502 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
P514 R503 ns
p
00MNN05221610 CHIP RES. 220 OHM +- 5% 1/16
W
P514 R504 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R505 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R506 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R507 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R508 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R509 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R510 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R511 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R512 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R513 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R514 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R515 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R516 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R517 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R518 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R519 ns
p
00MNN05220610 CHIP RES. 22 OHM +- 5% 1/16
W
P514 R520 ns
p
00MNN05220610 CHIP RES. 22 OHM +- 5% 1/16
W
P514 R522 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R523 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R524 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R525 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R526 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R527 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R528 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R529 00MBW05220020 00MBW05220020 RES. COMPO. CN1J4KTD22J
P514 R530 ns
p
00MNN05220610 CHIP RES. 22 OHM +- 5% 1/16
W
P514 R531 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
P514 R532 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
P514 R533 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +- 5% 1/16
W
P514 R539 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +- 5% 1/16
W
P514 R540 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +- 5% 1/16
W
P514 R544 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
P514 R545 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R546 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R547 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R548 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R549 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R550 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R551 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R552 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R553 ns
p
00MNN05220610 CHIP RES. 22 OHM +- 5% 1/16
W
P514 R554 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
P514 R555 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +- 5% 1/16
W
P514 R556 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R557 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R587 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16
W
P514 R588 ns
p
00MNN05330610 CHIP RES. 33 OHM +- 5% 1/16
W
P514 R589 ns
p
00MNN05221610 CHIP RES. 220 OHM +- 5% 1/16
W
P514 R590 ns
p
00MNN05181610 CHIP RES. 180 OHM +- 5% 1/16
W
P514 R591 ns
p
00MNN05820610 CHIP RES. 82 OHM +- 5% 1/16
W
231
