NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P814 C814 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P814 C816 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 C817 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 C824 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P814 C826 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 C827 ns
p
00MOA10802520 ELECT. CAP. 1000 UF M 25V RA-2
P814 C828 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
P814 C829 ns
p
00MDK16102300 CER. CAP. 1000PF K 50
V
P814 C830 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 C846 ns
p
00MOA10802520 ELECT. CAP. 1000 UF M 25V RA-2
P814 C847 ns
p
00MOA10802520 ELECT. CAP. 1000 UF M 25V RA-2
P814 C848 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 C849 ns
p
00MOA22802520 ELECT. CAP. 2200UF 25V RA2
P814 D801 00MHE20031290 00MHE20031290 DIODE ! D10SBS4-7100
P814 D802 00MHE20031290 00MHE20031290 DIODE ! D10SBS4-7100
P814 D803 00MHD20045290 00MHD20045290 DIODE ! D1NJ10 100V 1A SBD
P814 D804 00MHD20045290 00MHD20045290 DIODE ! D1NJ10 100V 1A SBD
P814 D805 00MHD20045290 00MHD20045290 DIODE ! D1NJ10 100V 1A SBD
P814 D806 00MHD20045290 00MHD20045290 DIODE ! D1NJ10 100V 1A SBD
P814 D807 00MHE20020290 00MHE20020290 DIODE ! D3SB 20 V=200V,IO=3.0
A
P814 Q806 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P814 Q807 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRANSISTOR RANK=Y
P814 Q808 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRANSISTOR RANK=Y
P814 Q809 00MBA10001000 00MBA10001000 TRS. DTA114ES/UN4111 10K,10
K
P814 R801 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P814 R802 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P814 R803 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P814 R804 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P814 R805 ns
p
00MGD05223160 RES. 22K OHM +- 5% 1/6
W
P814 R806 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
P814 R807 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6
W
P814 R808 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
REGULATOR2 PWB
(
00MWG12AJ602-
)
P824 C813 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C822 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C823 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C835 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C836 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C839 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C842 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 C845 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P824 D808 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D809 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D811 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D815 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D816 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D817 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D818 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 D819 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P824 Q803 00MHC36905210 00MHC36905210 IC ! BA05T 5V/1A TO220
P824 Q804 00MHC38915990 00MHC38915990 IC ! KIA7815API/P
P824 Q805 00MHC39915990 00MHC39915990 IC ! KIA7915PI/P
P824 Q811 00MHC38912990 00MHC38912990 IC ! KIA7812API/P
P824 Q812 00MHC38908990 00MHC38908990 IC ! KIA7808API/P
P824 Q813 00MHC38905990 00MHC38905990 IC ! KIA7805API/P
P824 Q814 00MHC38905990 00MHC38905990 IC ! KIA7805API/P
P824 Q815 00MHC39905990 00MHC39905990 IC ! KIA7905PI/P
FLD/BACKUP TRANS PWB
(
00MWG12AJ603-
)
P834 CB07 ns
p
00MOA10803520 ELECT. CAP. 1000 UF M 35V RA-2
P834 CB10 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P834 CB25 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P834 CB26 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P834 CB28 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P834 DB09 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P834 DB10 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P834 DB11 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P834 DB12 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
