Marantz SR9600 - Page 182

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
P834 DB26 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P834 LB05 00MLY1005013
0
00MLY1005013
0
RELAY ! SDT-S-105LMR
P834 QB08 00MHC38912990 00MHC38912990 IC ! KIA7812API/P
P834 TB01
/
F N ns
p
00MTS13521100 TRANSF. # POWER TRANS. FOR BACKUP 100V
P834 TB01
/
N1B 00MTS13521130 00MTS13521130 TRANSF. # POWER TRANS. FOR BACKUP 230V
P834 TB01
/
N1G 00MTS13521130 00MTS13521130 TRANSF. # POWER TRANS. FOR BACKUP 230V
P834 TB01
/
N1S 00MTS13521130 00MTS13521130 TRANSF. # POWER TRANS. FOR BACKUP 230V
P834 TB01
/
U1B ns
p
00MTS13521110 TRANSF. # POWER TRANS. FOR BACKUP 120V
P834 TB01
/
U1G ns
p
00MTS13521110 TRANSF. # POWER TRANS. FOR BACKUP 120V
P834 TB02
/
F N ns
p
00MTS13521140 TRANSF. # POWER TRANS. FOR FLD 100V
P834 TB02
/
N1B 00MTS13521170 00MTS13521170 TRANSF. # POWER TRANS. FOR FLD 230V
P834 TB02
/
N1G 00MTS13521170 00MTS13521170 TRANSF. # POWER TRANS. FOR FLD 230V
P834 TB02
/
N1S 00MTS13521170 00MTS13521170 TRANSF. # POWER TRANS. FOR FLD 230V
P834 TB02
/
U1B ns
p
00MTS13521150 TRANSF. # POWER TRANS. FOR FLD 120V
P834 TB02
/
U1G ns
p
00MTS13521150 TRANSF. # POWER TRANS. FOR FLD 120V
FLD/BACKUP POWER PWB
(
00MWG12AJ604-
)
P844 CB05 ns
p
00MOA47505020 ELECT. CAP. 4.7 UF M 50V RA-2
P844 CB11 ns
p
00MOA47802520 ELECT. CAP. 4700UF/25V RA-2
P844 CB14 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P844 CB17 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
P844 CB18 ns
p
00MOA10710020 ELECT. CAP. RA2-100V101MC-S1
P844 CB20 ns
p
00MOA10610020 ELECT. CAP. 10 UF M 100V RA2
P844 CB21 ns
p
00MOA10610020 ELECT. CAP. 10 UF M 100V RA2
P844 CB23 00MDK17471520 00MDK17471520 CER. CAP. ! DE0910 B 471K -KX 470PF 250
V
P844 DB05 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB06 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB07 00MHD30821000 00MHD30821000 ZENER DIODE 8.2V ZENER EQUIVALENT
P844 DB08 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P844 DB13 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB14 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB15 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB16 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB17 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB18 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB19 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB20 00MHD20002710 00MHD20002710 DIODE ! 1D3 1A/200
V
P844 DB21 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P844 DB22 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P844 DB23 00MHD33001000 00MHD33001000 ZENER DIODE ZENER 30V MTZ J 30
V
P844 DB24 00MHD33301000 00MHD33301000 ZENER DIODE MTZJ33D 33V ZENER EQUIVALEN
T
P844 DB25 ns
p
00MHD20002710 DIODE 1D3 1A/200
V
P844 QB07 00MHC10098550 00MHC10098550 IC PST600D-2 RESET IC
P844 QB09 00MHC36905210 00MHC36905210 IC ! BA05T 5V/1A TO220
P844 QB10 00MHC36J33210 00MHC36J33210 IC ! BA033T +3.3V 1A TYPE
P844 QB11 00MHT900291B0 00MHT900291B0 TRS. KTD600K NPN TRANSISTOR RANK=Y
P844 QB12 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
P844 QB13 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P844 QB14 00MHT600141B0 00MHT600141B0 TRS. KTA1271 PNP TRANSISTOR RANK=Y
P844 RB12 ns
p
00MGD05183160 RES. 18K OHM +- 5% 1/6
W
P844 RB13 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P844 RB15 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
P844 RB16 ns
p
00MGD05331160 RES. 330 OHM +- 5% 1/6
W
P844 RB22 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
P844 RB23 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
POWER SW PWB
(
00MWA11AJ409-
)
P894 C8P1
/
F N ns
p
00MDK17471520 CER. CAP. DE0910 B 471K -KX 470PF 250
V
P894 C8P1
/
N1B ns
p
00MDK17471520 CER. CAP. DE0910 B 471K -KX 470PF 250
V
P894 C8P1
/
N1G ns
p
00MDK17471520 CER. CAP. DE0910 B 471K -KX 470PF 250
V
P894 C8P1
/
N1S ns
p
00MDK17471520 CER. CAP. DE0910 B 471K -KX 470PF 250
V
P894 S8P1
/
F N ns
p
00MSP01013800 PUSH SW MAINS POWER SWITCH ESB92S17B
P894 S8P1
/
N1B 00MSP01013800 00MSP01013800 PUSH SW MAINS POWER SWITCH ESB92S17B
P894 S8P1
/
N1G 00MSP01013800 00MSP01013800 PUSH SW MAINS POWER SWITCH ESB92S17B
P894 S8P1
/
N1S 00MSP01013800 00MSP01013800 PUSH SW MAINS POWER SWITCH ESB92S17B
FRONT PWB
(
00MWA11AJ401-
)
PC14 CC06 ns
p
00MOA10610020 ELECT. CAP. 10 UF M 100V RA2
PC14 CC07 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PC14 CC08 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
