Marantz SR9600 - Page 183

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PC14 CC09 ns
p
00MOA10601620 ELECT. CAP. 10 UF M 16V RA-2
PC14 CCA1 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PC14 CCA2 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PC14 CCA3 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PC14 CCA4 ns
p
00MOA47701620 ELECT. CAP. 470UF 16V M RA-2
PC14 CCD4 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
PC14 CCE2 ns
p
00MDK16471300 CER. CAP. 470PF K 50
V
PC14 DC01 00MHW10002620 00MHW10002620 PHOTO UNIT IR SENSOR TSOP 1136 TB1
PC14 DC02 00MHI10045080 00MHI10045080 L.E.D. SML11516C-TP4
PC14 DC03 00MHI10044080 00MHI10044080 L.E.D. BLUE LED 3MM SEL2E10C
PC14 DC04 00MHI10005340 00MHI10005340 L.E.D. HLMF-K200 #2UL RED H=9 3MM
PC14 DCA1 ns
p
00MHD20045290 DIODE D1NJ10 100V 1A SBD
PC14 DCA2 ns
p
00MHD20045290 DIODE D1NJ10 100V 1A SBD
PC14 DCA3 ns
p
00MHD20045290 DIODE D1NJ10 100V 1A SBD
PC14 DCA4 ns
p
00MHD20045290 DIODE D1NJ10 100V 1A SBD
PC14 JC05 00MYJ0601313
0
00MYJ0601313
0
JACK 05JQ-ST
PC14 QC01 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
PC14 QC02 00MBA10001000 00MBA10001000 TRS. DTA114ES/UN4111 10K,10
K
PC14 QC03 00MBA10001000 00MBA10001000 TRS. DTA114ES/UN4111 10K,10
K
PC14 QC04 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
PC14 QC05 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
PC14 QC06 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
PC14 QCD1 00MHC10230210 00MHC10230210 IC BD6621FP-Y
PC14 QCE1 00MHC10009090 00MHC10009090 IC NJM2901 QUAD COMPARATOR
PC14 RC01 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PC14 RC02 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PC14 RC03 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
PC14 RC04 ns
p
00MGD05331160 RES. 330 OHM +- 5% 1/6
W
PC14 RC05 ns
p
00MGD05681160 RES. 680 OHM +- 5% 1/6
W
PC14 RC06 ns
p
00MGD05331160 RES. 330 OHM +- 5% 1/6
W
PC14 RC07 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC08 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC09 ns
p
00MGD05222160 RES. 2.2K OHM +- 5% 1/6
W
PC14 RC10 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
PC14 RC11 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC12 ns
p
00MGD05821160 RES. 820 OHM +- 5% 1/6
W
PC14 RC13 ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC14 ns
p
00MGD05222160 RES. 2.2K OHM +- 5% 1/6
W
PC14 RC15 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
PC14 RC16 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC17 ns
p
00MGD05821160 RES. 820 OHM +- 5% 1/6
W
PC14 RC18 ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC19 ns
p
00MGD05222160 RES. 2.2K OHM +- 5% 1/6
W
PC14 RC20 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
PC14 RC21 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC22 ns
p
00MGD05821160 RES. 820 OHM +- 5% 1/6
W
PC14 RC23
/
F N ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC23
/
N1B ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC23
/
N1G ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC23
/
N1S ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC24
/
U1B ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC24
/
U1G ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC25 ns
p
00MGD05222160 RES. 2.2K OHM +- 5% 1/6
W
PC14 RC26 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
PC14 RC27 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 RC28 ns
p
00MGD05821160 RES. 820 OHM +- 5% 1/6
W
PC14 RC29 ns
p
00MGD05561160 RES. 560 OHM +- 5% 1/6
W
PC14 RC33 ns
p
00MGD05473160 RES. 47K OHM +- 5% 1/6
W
PC14 RCD4 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
PC14 RCD5 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
PC14 RCD9 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6
W
PC14 RCE1 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PC14 RCE2 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PC14 RCE3 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PC14 RCE4 ns
p
00MGD05104160 RES. 100K OHM +- 5% 1/6
W
PC14 RCE5 ns
p
00MGD05472160 RES. 4.7K OHM +- 5% 1/6
W
PC14 RCI1 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
241
