Marantz SR9600 - Page 184

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PC14 RCI2 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC14 SC01 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC02 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC03 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC04 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC05 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC06 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC07 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC08 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC09 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC10 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC11 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC12 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC13 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC14 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC15 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC16 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC17 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC18 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC19 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC20 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC21 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC22 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SC23 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC14 SCI1 00MSR02010080 00MSR02010080 ROTARY SW ROT,ENCOD EC16B 16PLS 16CLIC
K
PC14 VC01 00MHQ38701920 00MHQ38701920 DISPLAY MN25664J
RC-TRANSMITT PWB
(
00MWA11AJ402-
)
PC24 DC50 00MHI20006030 00MHI20006030 GAS LED GL-350 SLR-932AV-8K A RANK 5MM P2.5
PC24 DC51 00MHI20006030 00MHI20006030 GAS LED GL-350 SLR-932AV-8K A RANK 5MM P2.5
PC24 DC52 00MHI20006030 00MHI20006030 GAS LED GL-350 SLR-932AV-8K A RANK 5MM P2.5
PC24 DC53 00MHI20006030 00MHI20006030 GAS LED GL-350 SLR-932AV-8K A RANK 5MM P2.5
PC24 QC50 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PC24 QC51 00MHT321201A0 00MHT321201A0 TRS. 2SC2120 O
PC24 QC52 00MHT321201A0 00MHT321201A0 TRS. 2SC2120 O
PC24 RC56 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
PC24 RC57 ns
p
00MGD05152160 RES. 1.5K OHM +- 5% 1/6
W
CONNECTION 1
(
FL CPU
)
PWB
(
00MWG12AJ503-
)
PC34 CC80 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CC81 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CC82 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC85 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC86 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16
V
PC34 CC87 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC88 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC89 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC90 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC91 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1U
F
PC34 CC95 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CC97 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CCA1 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CCA2 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CCA3 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 CCA4 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PC34 QC80 90M-HS11AJH0R 90M-HS11AJH0R U-PRO HD64F2398F20 MCU
(
PROG.00M11AJ499C00
)
PC34 RC71 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC72 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC73 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC74 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC75 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC76 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC77 ns
p
00MNN05100610 CHIP RES. 10 OHM +- 5% 1/16
W
PC34 RC80 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PC34 RC81 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PC34 RC82 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PC34 RC83 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PC34 RC85 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PC34 RC86 ns
p
00MNN05104610 CHIP RES. 100K OHM +- 5% 1/16
W
242
