Marantz SR9600 - Page 185

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PC34 RC94 ns
p
00MNN05473610 CHIP RES. 47K OHM +- 5% 1/16
W
PC34 RC95 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PC34 RC96 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PC34 RC97 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PC34 RC98 ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PC34 XC80 00MFQ02005070 00MFQ02005070 CER. VIB. CSTCE20M0V53-R0
STANDBY PWB
(
00MWA11AJ405-
)
PC54 SC24
/
U1B ns
p
00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
PC54 SC24
/
U1G ns
p
00MSP01013370 PUSH SW EVQ11L05R H/5MM,160G
F
GYRO PWB
(
00MWA11AJ406-
)
PC64 RCG1 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC64 RCG2 ns
p
00MGD05102160 RES. 1K OHM +- 5% 1/6
W
PC64 SCG1 00MSR02010130 00MSR02010130 ROTARY SW EC12E2420802
MIC PWB
(
00MWA11AJ408-
)
PC84 JCM1 00MYJ0100471
0
00MYJ0100471
0
JACK HEADPHONE JACK YKB21-5144
PC84 RCM3 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6
W
DAC
,
VOL PWB
(
00MWG12AJ701-
)
PD14 CD02 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD14 CD14 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD14 CD26 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD14 CD38 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PD14 CD50 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD51 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD52 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
PD14 CD53 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD58 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD59 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD60 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
PD14 CD61 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD66 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD67 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD68 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
PD14 CD69 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD74 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD75 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CD76 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
PD14 CD77 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PD14 CE01 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE02 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE03 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE04 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE08 ns
p
00MDD95471300 CER. CAP. GRM39CH471J50P
T
PD14 CE09 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE10 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE11 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE12 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V P
P
PD14 CE16 ns
p
00MDD95471300 CER. CAP. GRM39CH471J50P
T
PD14 CE20 ns
p
00MOA22602520 ELECT. CAP. 22 UF M 25V RA-2
PD14 CE21 ns
p
00MOA22602520 ELECT. CAP. 22 UF M 25V RA-2
PD14 CE24 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE25 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE26 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE27 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE28 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PD14 CE29 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE30 ns
p
00MOA22602520 ELECT. CAP. 22 UF M 25V RA-2
PD14 CE31 ns
p
00MOA22602520 ELECT. CAP. 22 UF M 25V RA-2
PD14 CE34 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE35 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE36 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE37 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE38 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PD14 CE39 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
PD14 CE44 00MOF15471540 00MOF15471540 FILM CAP. APSV 471J,470PF
(
TP
)
100V PP
PD14 CE45 00MOF15471540 00MOF15471540 FILM CAP. APSV 471J,470PF
(
TP
)
100V PP
PD14 CE54 00MOF15471540 00MOF15471540 FILM CAP. APSV 471J,470PF
(
TP
)
100V PP
PD14 CE55 00MOF15471540 00MOF15471540 FILM CAP. APSV 471J,470PF
(
TP
)
100V PP
