NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PS14 CY11 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 CY13 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PS14 CY14 ns
p
00MDD95470300 CER. CAP. 47 PF +- 5 % CG 50V GR39
PS14 CY16 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY17 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY18 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY19 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY20 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY21 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY22 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY23 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY24 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY25 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
PS14 CY31 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 CY32 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 CY33 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 CY34 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 CY35 ns
p
00MDD95101300 CER. CAP. 100 PF +- 5 % CG 50V GR39
PS14 DI01 00MHZ30009020 00MHZ30009020 CHIP DIODE MA8075M 7.5
V
PS14 DI02 00MHZ30009020 00MHZ30009020 CHIP DIODE MA8075M 7.5
V
PS14 DI03 00MHZ30471000 00MHZ30471000 CHIP DIODE MA8047-M 4.7
V
PS14 DI04 00MHZ30009020 00MHZ30009020 CHIP DIODE MA8075M 7.5
V
PS14 DI05 00MHZ30009020 00MHZ30009020 CHIP DIODE MA8075M 7.5
V
PS14 DI06 00MHZ30471000 00MHZ30471000 CHIP DIODE MA8047-M 4.7
V
PS14 DI07 00MHZ20001290 00MHZ20001290 CHIP DIODE D1F60-4063
PS14 DI08 00MHZ20001290 00MHZ20001290 CHIP DIODE D1F60-4063
PS14 DI09 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DI10 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DI11 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DM01 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY01 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY02 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY03 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY04 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY05 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 DY13 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PS14 JS02 00MYT02060670 00MYT02060670 TERMINAL 14X14 RA 2L6 WH+RE AU F-GROUND
PS14 JS03 00MYT02060670 00MYT02060670 TERMINAL 14X14 RA 2L6 WH+RE AU F-GROUND
PS14 JS04 00MYT02060670 00MYT02060670 TERMINAL 14X14 RA 2L6 WH+RE AU F-GROUND
PS14 JS06 00MYT02041280 00MYT02041280 TERMINAL 14X14 RA 2L4 WH+RE AU F-FROUND
PS14 JS07 00MYT02041280 00MYT02041280 TERMINAL 14X14 RA 2L4 WH+RE AU F-FROUND
PS14 LM01 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PS14 LM02 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24USR
PS14 LT01
/
N1B 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT01
/
N1G 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT01
/
N1S 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT02
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT02
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT02
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT03
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT03
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT03
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT04
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT04
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT04
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT05
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT05
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT05
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT06
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT06
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT06
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT11
/
N1B 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT11
/
N1G 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT11
/
N1S 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT12
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT12
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
PS14 LT12
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM +- 5% 1/16
W
