NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
PS14 LT13
/
N1B 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT13
/
N1G 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT13
/
N1S 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT21 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT22 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT23 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT24 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT25 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT26 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT27 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT28 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT31 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT32 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT33 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT34 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT35 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT36 00MFM3147401
0
00MFM3147401
0
EMI FILTER NFM2012P13C474R
PS14 LT37 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 LT38 ns
p
00MNN05101610 CHIP RES. 100 OHM +- 5% 1/16
W
PS14 QI01 00MHT700241B0 00MHT700241B0 TRS. KTB631K PNP TRANSISTOR RANK=Y
PS14 QI02 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PS14 QI03 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PS14 QI04 00MHT900291B0 00MHT900291B0 TRS. KTD600K NPN TRANSISTOR RANK=Y
PS14 QI05 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QI06 00MHT700241B0 00MHT700241B0 TRS. KTB631K PNP TRANSISTOR RANK=Y
PS14 QI07 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911S-GR
PS14 QI08 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517S-GR
PS14 QI09 00MHT900291B0 00MHT900291B0 TRS. KTD600K NPN TRANSISTOR RANK=Y
PS14 QI10 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QI11 00MHC38906990 00MHC38906990 IC KIA7806API/P
PS14 QI12 00MHC39906990 00MHC39906990 IC KIA7906PI/P
PS14 QI13 00MHT700241B0 00MHT700241B0 TRS. KTB631K PNP TRANSISTOR RANK=Y
PS14 QI14 00MHX300012B0 00MHX300012B0 CHIP TRS. 2SC4081
(
R.S
)
2SC4116
(
GR.BL
)
PS14 QK01 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QK02 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QK03 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QK04 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QM01 00MHC10240090 00MHC10240090 IC NJW1157BFC2
PS14 QM02 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QM03 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM04 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM06 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QM07 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM08 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM10 00MBA20035210 00MBA20035210 TRS. DTC114EU
PS14 QM11 00MHT108172B0 00MHT108172B0 TRS. 2SA817 O OR Y 600MW -300M
A
PS14 QM12 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QM13 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM14 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM15 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QM16 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QM17 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PS14 QS01 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS02 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS03 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS04 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS05 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS06 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS07 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS08 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS09 00MHC10102090 00MHC10102090 IC NJM2068M-TE1
PS14 QS10 00MHC10466050 00MHC10466050 IC TC9274N-016 ANALOG SWITCH
PS14 QT01
/
N1B 00MHC10404030 00MHC10404030 IC LC72722 RDS DECODER
PS14 QT01
/
N1G 00MHC10404030 00MHC10404030 IC LC72722 RDS DECODER
PS14 QT01
/
N1S 00MHC10404030 00MHC10404030 IC LC72722 RDS DECODER
PS14 QT02
/
N1B 00MHX300012B0 00MHX300012B0 CHIP TRS. 2SC4081
(
R.S
)
2SC4116
(
GR.BL
)
PS14 QT02
/
N1G 00MHX300012B0 00MHX300012B0 CHIP TRS. 2SC4081
(
R.S
)
2SC4116
(
GR.BL
)
