WARNING – The operator of the press should always stand in front of the machine,
facing the tablet with hands near the tablet to press the STOP button in the event the
press needs to stop. You should visually see the decapping die spent primers and watch
for bullets toppling or powder spilling. The best vantage point for this is standing to the
front left or right side of the machine.
Figure 20: Tablet Holder orientation for 9 inch tablet (left) 10 inch (Right)
Figure 21: Side view of Tablet holder 9 inch (left) 10 inch (Right)
