Technical Notice V1.0 / 01.09 Page 19 / 100
Generalities 2
2.3.3 Separated tank and refrigeration units
For refrigeration units of greater capacity, the refrigerant liquid returned is stored in a reservoir (10) then
pumped (1) and chilled (11) before being returned back to the cooling circuit (8)..
Fig. 2-2 : Basic schematic
TH
HPBP
(7)(6)(4)(3)(2)(1)
(8) (9) (10) (11) (12) (14)(13)
(5)
