Technical Notice V1.0 / 01.09 Page 71 / 100
Model CSW 600/800 11
11.1.2 Technical specifications
11.1.2.1 Standard operating parameters
11.1.2.2 Electrical data
11.1.2.3 Air condenser
Evaporator
Description Units CSW 600/800
Refrigerant Type R407C
Refrigerating capacity kW 7900
Power consumption kW 1500
Heat load kW 7500
Inlet temperature °C 25
Outlet temperature °C 20
Flow rate l/min 20
Maximum input temperature °C 38
Table 11-1:
Description Units CSW 600/800
Power input kW 3
Maximum amperage A 9,5
Start-up amperage A 30
Line fuse A T 10
Power supply V x ph x Hz 400 x 3 x 50
Table 11-2:
Description Units CSW 600/800
Flow rate m3/h 1585
Exhaust fan diameter mm 350
Power input W 135
Ampere rating A 0,32
Power supply V x ph x Hz 400 x 3 x 50
Table 11-3:
Description Units CSW 600/800
Composition COPPER
Table 11-4:
