Page 72 / 100 Technical Notice V1.0 / 01.09
11 Model CSW 600/800
Hydraulic circui
Dimensions
Other characteristics
Flow rate l/min 20
Charge loss bar 0,2
Description Units CSW 600/800
Flow rate l/min 20
Total p re ssu re bar 1,5
Power input kW 0,37
Amperage A 1,8
Rotation t/min 2900
Power supply V x ph x Hz 400 x 3 x50
Stainless steel reservoir l 55
Inlet/outlet couplings 3/4 ‘’
Table 11-5:
Description Units CSW 600/800
Width mm 550
Height mm 900
Depth mm 600
Weight kg 112
Table 11-6:
Description Units CSW 600/800
Standard colour RAL 7035
Sound rating
ISO 3741 – Lp
dB(A) 50
Table 11-7:
Description Units CSW 600/800
Table 11-4:
