Model CSW 100/150 4
Chapter contents
This chapter contains information specific to the CSW 100 and CSW 150 models. It covers all topics as-
sociated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 100 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 150 model.
4.1 Description
4.1.1 Overall view
(1) Lifting ring
(2) Breakdown indicator lamp (red)
(3) Water-level indicator lamp (orange, optional)
(4) Thermostat display
(5) Purge button
(6) Main power switch
Fig. 4-1 : CSW 100 type chiller
(1) (2) (3) (4) (5) (6)
