Technical Notice V1.0 / 01.09 Page 69 / 100
Model CSW 2000/2400 11
Chapter contents
This chapter contains information specific to the CSW 2000 and CSW 2400 models. It covers all topics
associated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 2000 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 2400 model.
11.1 Description
11.1.1 Overall view
(1) Programmable controller display (optional, visible after opening the door)
(2) Thermostat display
(3) Breakdown indicator lamp (red)
(4) Main power switch
Fig. 11-1 : CSW 2000 type chiller (front view)
