Technical Notice V1.0 / 01.09 Page 69 / 100
Model CSW 3000/3500/4700 11
Chapter contents
This chapter contains information specific to the CSW 3000, CSW 3500 and CSW 4700 models. It co-
vers all topics associated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 3000 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 3500 and CSW 4700 models.
11.1 Description
11.1.1 Overall view
(1) Programmable controller display (optional, visible after opening the door)
(2) Breakdown indicator lamp (red)
(3) Thermostat display
(4) Main power switch
(5) Output circuit pressure gauge (on request)
(6) Drainage tap
Fig. 11-1 : CSW 3000 type chiller (front view)
