Marksa CSSW 50 - Technical Specifications

Technical Notice V1.0 / 01.09 Page 71 / 100
Model CSW 2000/2400 11
11.1.2 Technical specifications
11.1.2.1 Standard operating parameters
11.1.2.2 Electrical data
11.1.2.3 Air condenser
Evaporator
Description Units CSW 2000 CSW 2400
Refrigerant Type R407C R407C
Refrigerating capacity kW 20,0 24,0
Power consumption kW 6,7 7,4
Heat load kW 26,7 31,4
Inlet temperature °C 27 28
Outlet temperature °C 20 20
Flow rate l/min 40 40
Maximum input temperature °C 42 42
Description Units CSW 2000 CSW 2400
Power input kW 8,0 9,0
Maximum amperage A 16 18
Start-up amperage A 50 60
Line fuse A T 20 20
Power supply V x ph x Hz 400 x 3 x 50
Description Units CSW 2000 CSW 2400
Flow rate m3/h 8600 8600
Exhaust fan diameter mm 500 500
Power input W 500 500
Ampere rating A 1,2 1,2
Power supply V x ph x Hz 400 x 3 x 50 400 x 3 x 50
Description Units CSW 2000 CSW 2400
Composition AISI316 AISI316
Flow rate l/min 40 40
Charge loss bar 0,2 0,2
