11 Model CSW 2000/2400
(5) Electric power connector (optional)
(6) Output circuit pressure gauge
(7) Cooling liquid outlet
(8) Cooling liquid return inlet
(9) Drainage tap
Fig. 11-2 : CSW 2000 type chiller (rear view)
