Marksa CSSW 50 - Technical Specifications

Technical Notice V1.0 / 01.09 Page 23 / 100
Model CSW 50/65/80 3
3.1.2 Technical specifications
3.1.2.1 Standard operating parameters
3.1.2.2 Electrical data
3.1.2.3 Air condenser
Evaporator
Description Units CSW 50 CSW 65/80
Refrigerant Type R134A R134A
Refrigerating capacity kW 0.5 0.8
Power consumption kW 0.23 0.41
Heat load kW 0.75 1.2
Inlet temperature °C 22 22
Outlet temperature °C 20 20
Flow rate l/min 8 8
Maximum input temperature °C 38 38
Description Units CSW 50 CSW 65/80
Power input kW 0.4 0.6
Maximum amperage A 2.5 3
Start-up amperage A 7 10
Line fuse A T 10 10
Power supply V x ph x Hz 230 x 1 x 50 230 x 1 x 50
Description Units CSW 50 CSW 65/80
Flow rate m3/h 245 580
Exhaust fan diameter mm 200 254
Power input W 5 16
Ampere rating A 0.2 0.58
Power supply V x ph x Hz 230 x 1 x 50 230 x 1 x 50
Description Units CSW 50 CSW 65/80
Composition COPPER COPPER
Flow rate l/min 8 8
