Page 34 / 100 Technical Notice V1.0 / 01.09
5 Model CSW 200/300
5.1.2 Technical specifications
5.1.2.1 Standard operating parameters
5.1.2.2 Electrical data
5.1.2.3 Air condenser
Evaporator
Description Units CSW 200/300 CSW200E/300E
Refrigerant Type R134A R134A
Refrigerating capacity W 3000 3000
Power consumption W 1355 1355
Heat load W 4355 4355
Inlet temperature °C 25 25
Outlet temperature °C 20 20
Flow rate l/min 8 10
Maximum input temperature °C 38 38
Description Units CSW 200/300 CSW200E/300E
Power input kW 1.70 1.70
Maximum amperage A 9 3.25
Start-up amperage A 36 15
Line fuse A T 10 6
Power supply V x ph x Hz 230 x 1 x 50 400 x 3 x 50
Description Units CSW 200/300 CSW200E/300E
Flow rate m3/h 700 800
Exhaust fan diameter mm 275 275
Power input W 25 25
Ampere rating A 0.75 0.49
Power supply V x ph x Hz 230 x 1 x 50 400 x 3 x 50
Description Units CSW 200/300 CSW200E/300E
Composition COPPER COPPER
Flow rate l/min 8 10
