Page 84 / 100 Technical Notice V1.0 / 01.09
12 Options
12.12 Contrôle de niveau (N)
12.12.1 Description of the option
A float in the reservoir makes it possible to check on the liquid levels. If the level is too low, in order to
avoid any damage, the refrigeration unit stops itself and an alarm is shown on the programmable control-
ler display and/or on the visual display located on the front panel.
It is recommended to fill the tank up to the visual display level.
12.12.2 Maintenance
No special maintenance procedures.
12.12.3 Breakdowns
The float no longer indicates the actual water level (float is blocked)
- Non-standard antifreeze product or no anti-freeze
✔ Drain the reservoir
Clean the level
Put in compliant refrigerant liquid
Fig. 12-8 : Basic schematic
