Marksa CSSW 50 - 5 Model CSW 200;300 5; Description; Overall View

Technical Notice V1.0 / 01.09 Page 33 / 100
Model CSW 200/300 5
Chapter contents
This chapter contains information specific to the CSW 200 and CSW 300 models. It covers all topics as-
sociated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 200 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 300 model.
5.1 Description
5.1.1 Overall view
(1) Programmable controller display (optional)
(2) Thermostat display
(3) Breakdown indicator lamp (red)
(4) Main power switch
(5) Refilling port
(6) Visual water-level indicator
Fig. 5-1 : CSW 200 type chiller
(1) (2) (3) (4)
(5) (6)
