Model CSW 900/1000/1300/1700 11
Chapter contents
This chapter contains information specific to the CSW 900, CSW 1000, CSW 1300 et CSW 1700models.
It covers all topics associated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 1000 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 900, CSW 1300 et CSW 1700 models.
11.1 Description
11.1.1 Overall view
(1) Programmable controller display (optional, visible after opening the door)
(2) Thermostat display
(3) Breakdown indicator lamp (red)
(4) Main power switch
Fig. 11-1 : CSW 1000 type chiller (front view)
