11 Model CSW 900/1000/1300/1700
(5) Electric power connector
(6) Cooling liquid return inlet
(7) Cooling liquid outlet
(8) Visual water-level indicator
(9) Drainage tap
Fig. 11-2 : CSW 1000 type chiller (rear view)
