12 Options
12.3 By-pass (J)
12.3.1 Description of the option
In the event of excessive pressure in the outlet port of the refrigeration unit, the bypass is engaged and
reinjects the liquid into the reservoir in order to avoid damages in the external circuit.
12.3.2 Maintenance
The bypass is regulated in the factory. No maintenance or adjustment by the customer is autho-
rised.
12.3.3 Breakdowns
No special breakdown procedures.
Fig. 12-2 : Basic schematic
TH
BP - HP
(1)
