Technical Notice V1.0 / 01.09 Page 71 / 100
Model CSW 900/1000/1300/1700 11
11.1.2 Technical specifications
11.1.2.1 Standard operating parameters
11.1.2.2 Electrical data
11.1.2.3 Air condenser
Description Units CSW 900/1000 CSW 1300 CSW 1700
Refrigerant Type R407C R407C R407C
Refrigerating capacity kW 9.7 12 16,4
Power consumption kW 2.2 3.5 4.5
Heat load kW 11,9 15,5 20.9
Inlet temperature °C 27 25 27
Outlet temperature °C 20 20 20
Flow rate l/min 20 35 35
Maximum input temper-
ature
°C 38 38 38
Table 11-1:
Description Units CSW 900/1000 CSW 1300 CSW1700
Power input kW 4 4.5 5.5
Maximum amperage A 12 13 16
Start-up amperage A 40 45 50
Line fuse A T 16 16 20
Power supply V x ph x Hz 400 x 3 x 50 400 x 3 x 50 400 x 3 x 50
Table 11-2:
Description Units CSW 900/1000 CSW 1300 CSW 1700
Flow rate m3/h 3350 3350 3350
Exhaust fan diameter mm 420 420 420
Power input W 270 270 300
Ampere rating A 0.65 0.65 0.7
Power supply V x ph x Hz 400 x 3 x 50 400 x 3 x 50 400 x 3 x 50
Table 11-3:
