Marksa CSSW 50 - Technical Specifications

Technical Notice V1.0 / 01.09 Page 71 / 100
Model CSW 3000/3500/4700 11
11.1.2 Technical specifications
11.1.2.1 Standard operating parameters
11.1.2.2 Electrical data
11.1.2.3 Air condenser
Evaporator
Description Units CSW 3000 CSW 3500 CSW 4700
Refrigerant Type R407C R407C R407C
Refrigerating capacity kW 30,0 35,0 47,0
Power consumption kW 8,4 10,7 9,55
Heat load kW 38,4 45,7 56,55
Inlet temperature °C 25 26 26
Outlet temperature °C 20 20 20
Flow rate l/min 75 75 115
Maximum input temperature °C 42 42 42
Description Units CSW 3000 CSW 3500 CSW 4700
Power input kW 12,0 13,0 15,0
Maximum amperage A 24 26 28
Start-up amperage A 75 80 90
Line fuse A T 30 30 30
Power supply V x ph x Hz 400 x 3 x 50 400 x 3 x 50 400 x 3 x 50
Description Units CSW 3000 CSW 3500 CSW 4700
Flow rate m3/h 11000 9200 2 x 8600
Exhaust fan diameter mm 2 x 400 2 x 500 2 x 500
Power input W 2 x 160 2 x 770 2 x 500
Ampere rating A 2 x 0,73 2 x 3,4 2 x 1,2
Power supply V x ph x Hz 230 x 3 x 50 230 x 3 x 50 400 x 3 x 50
Description Units CSW 3000 CSW 3500 CSW 4700
Composition AISI316 AISI316 AISI316
Flow rate l/min 75 75 115
