This chapter contains information specific to the CSW 600 and CSW 800 models. It covers all topics as-
sociated with installation, commissioning, tuning and maintenance of these models.
For reasons of clarity, only the CSW 800 model is described in the current chapter. However, all
of the explanations apply in a similar fashion to the CSW 600 model.
11.1 Description
11.1.1 Overall view
(1) Programmable controller display (optional, visible after opening the door)
(2) Thermostat display
(3) Breakdown indicator lamp (red)
(4) Main power switch
Fig. 11-1 : CSW 800 type chiller (front view)
