Page 72 / 100 Technical Notice V1.0 / 01.09
11 Model CSW 900/1000/1300/1700
Evaporator
Hydraulic circui
Dimensions
Other characteristics
Description Units CSW 900/1000 CSW 1300 CSW 1700
Composition AISI 316 AISI 316 AISI 316
Flow rate l/min 20 40 40
Charge loss bar 0,2 0,25 0,25
Table 11-4:
Description Units CSW 900/1000 CSW 1300 CSW 1700
Flow rate l/min 20 35 35
Total pressure bar 2 2,5 2,5
Power input kW 0,37 0,37 0,37
Amperage A 1,8 1,8 1,8
Rotation t/min 2900 2900 2900
Power supply V x ph x Hz 400 x 3 x 50 400 x 3 x 50 400 x 3 x 50
Stainless steel reservoir l 60 60 145
Inlet/outlet couplings 1 “ 1 “ 1 “
Table 11-5:
Description Units CSW 900/1000 CSW 1300 CSW 1700
Width mm 700 700 700
Height mm 1300 1300 1300
Depth mm 850 850 850
Weight kg 230 245 275
Table 11-6:
Description Units CSW 900/1000 CSW 1300 CSW 1700
Standard colour RAL 7035 7035 7035
Sound rating
ISO 3741 – Lp
dB(A) 65 65 65
Table 11-7:
