• Subnet Mask: This is the mask to be applied on destination address.
• Gateway Address: This is the IP address of the node where the IP packets are to be sent. Generally, it
is the IP address of the LAN interface of the Router.
The Gateway Address must be in the same subnet as SETU VFXTH.
• Click Submit to save your entries.
To take the above example further, the Static Routing Table of SETU VFXTH at Location A should be
configured as:
• The Destination Address 192.168.2.0 specifies the network address of Location B.
• The Subnet Mask is the mask to be applied on the Destination address.
• The Gateway Address 192.168.1.1 specifies the LAN address of the Router A which connects location
A and location B.
The IP address of the LAN interface of the router which connects Location A to the public internet
should be configured as Default Gateway in the Network Parameters of SETU VFXTH at location A.
With the Static Routing Table configured thus, all calls made by SETU VFXTH to 192.168.2.0/ 24 will be
routed through the router which connects Location A to Location B. Whereas, all calls made by SETU
VFXTH to address other than 192.168.2.0/ 24 will be routed through the Default Gateway.
Similarly, configure the Static Routing Table in SETU VFXTH at location B to enable calling from
Location B to Location A.
Index Destination Address Subnet Mask Gateway Address
1 192.168.2.0 255.255.255.0 192.168.1.1
2
:
8
