During normal functioning, FXS and FXO Port LEDs will display following error/events/status:
During Off-hook state, FXS Port LED glows continuous Red. However, if the system is in programming
mode, the LED of the port from which you entered the programming mode will glow continuously Green.
After exiting the programming mode, the LED will turn Red again (displaying Off-hook event).
When the Reset Cycle is completed, you may configure the system using the embedded web server, Jeeves.
LED Status Colour Event/State/Status
Continuous OFF - Port Idle/Disable
400ms On - 200ms Off -
400ms On - 3000ms Off (2 Blinks)
Red Incoming Ring Event
400ms On - 400ms Off (continuous) Red Off-hook Event (Dialing State)
Continuous On Red Speech
