Powering ON SETU VFXTH
• Connect the power adapter into the power jack, and plug it into a power outlet.
• Switch ON power supply and observe the reset cycle.
LED Indication
At Power ON, Power LED will turn ON (Continuous Green). Initialization process will start within 15 to 20 seconds
and LED sequence of all other LEDs during initialization process is shown in the table given below:
During initialization, System LED (STS) will display following error/events/status:
System Status Color STS P01 P02 P03 P04 P05 P06 …. P32
Time
(ms)
Application Load Red OFF ON ON ON OFF OFF OFF OFF OFF
All Init Done,
System goes
Live
Red ON ON ON ON ON ON ON ON ON 1000 ms
OFF OFF OFF OFF OFF OFF OFF OFF OFF 1000 ms
LED Status Colour Comment
Continuous On Red VoPP program download fail / Port
not detected / System Error.
2000 ms On (Red)
5000 ms On (Green)
Red and Green Modules not detected.
1sec On - 1sec Off Green SETU VFXTH started successfully.
Network link is Up.
SIP stack is Up.
CDR buffer is not full.
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off (4 Blinks)
Green Network link is down.
SIP stack is down.
CDR buffer is not full.
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 1500ms off (3 Blinks)
Green Network link is Up.
SIP stack is down.
CDR buffer is not full.
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 500ms off (4 Blinks)
Red Network link is down.
SIP stack is down.
CDR buffer is full.
1sec On - 1sec Off Red Network link is up.
SIP stack is down.
CDR buffer is full.
500 ms on - 500ms off -
500 ms on - 500ms off -
500 ms on - 1500ms off (3 Blinks)
Red Network link is up.
SIP stack is up.
CDR buffer is full.
