FXO Port Parameters
VoIP Parameters
Transmission Level Adjust Tx Gain: -3dB to +6dB; Rx Gain: -3dB to +6dB
Answer Signaling on FXS Battery Reversal
Disconnect Signaling on FXS Battery Reversal and Open Loop Disconnect
Signaling Loop Start
Connector RJ11
Off-hook Line Impedance 600/900/Complex
Loop Limit 1200
Pulse Dialing 10PPS and 20PPS
DTMF Dialing and Reception ITU-T Q.23 and Q.24
CLI Reception DTMF, FSK ITU-T V.23 and FSK Bellcore 202
Protection Over Voltage and Over Current Secondary Protection
Return Loss >18dB
Longitudinal Balance >50dB
Transmission Level Adjust Tx Gain: -15dB to +10dB; Rx Gain: -15dB to +10dB
Call Maturity Delay and Polarity Reversal
Answer Supervision on FXO Battery Reversal
Disconnect Supervision on FXO Battery Reversal and Open Loop Disconnect
Connector RJ45
VoIP Protocols SIP v2, SDP, RTP (RFC 2833), SRTP
Network Protocols IPv4, TCP, UDP, DHCP, SNTP, STUN, HTTP, TLS
SIP 32 SIP Trunks with Out Bound Proxy Support
NAT STUN and NAT Keep Alive
Voice Codec's G.711 (a-Law and mu-Law), G.729, G.723, GSM FR, iLBC-30ms and iLBC-20ms
Line Echo Cancellation G.168 with 128ms Tail Length
Call Progress Tones Dial Tone, Ring Back Tone, Busy Tone, Error Tone
Voice Dynamic Jitter Buffer (Adaptive), Comfort Noise Generation and Voice Activity
Detection
Fax T.38(UDPTL), T.38(RTP) and Pass Through
Quality of Service Layer 3 Diffserv and TOS
Data Network WAN Port RJ45 Auto MDIX 10/100 Base T
Security Password Protected Administration
