45 Matrix SETU VFXTH System Manual
• In the Destination Number field, enter the number (24 characters, maximum) that you expect callers
to dial. Valid digits: 0–9, *, #, (dot). Default: Blank.
• In the Minimum Digits field, enter the minimum number of digits of the destination number that the
caller must dial for the system to route the call. Valid range: 01–24. Default: 3.
If the dialed number string is less than the configured minimum length, the call will be rejected.
• In the Maximum Digits field, enter the maximum number of digits to be dialed by the caller for the
system to consider it as end-of-dialing for routing the call. Valid range: 01–24. Default:16.
If the number string dialed by the caller exceeds the maximum length configured, the system will strip
off the extra digits, and route the call.
• Select the CLI Number to be sent on Destination Port. You may select from the following options:
• Received Calling Party
• Received Called Party
Default: Received Calling Party
CLI Number to be sent on Destination Port is applicable only when FXS Port or FXS Group is selected
as the Destination Port (Routing Group).
• Create the Routing Group.
• To create a group of sequential FXS Ports as members,
• Select the desired FXS Port numbers as members. Default: 1.
• In the in - order box, select the order in which the system should hunt for a free member FXS
Port to route the call.
Select Ascending to start hunting from the first to the last member FXS Port.
Select Descending to start hunting from the last to the first member FXS Port. Default:
Ascending.
• To create a group of not-sequential FXS Ports as members,
• Select an FXS Group.
• Select FXS Group number. Default:1.
• Click Settings . The FXS Groups window opens. Create the FXS Group. For detailed
instructions, see “Group”.
• Similarly, you can create group of sequential and not-sequential FXO Ports and SIP Trunks as
members.
• You may create the Fallback Routing Group. To do this,
• Select the Apply check box.
