Matrix VISIONPRO System Manual 42
Default Transmit Gain Code is 01.
• To configure the same Transmit Gain for all stations at once, dial,
4106-*-Code
• To configure the Receive Gain for a station, dial,
4107-1-Station-Code
Where,
Station is the software port number of the station from 00 to 07.
03 6
04 5.5
05 5
06 4.5
07 4
08 3.5
09 2.5
10 2
11 1.5
12 1
13 0.5
14 -0.5
15 -1
16 -1.5
17 -2
18 -2.5
19 -3.5
20 -4
21 -4.5
22 -5
23 -5.5
24 -6
25 -6.5
26 -7
27 -7.5
28 -8
29 -8.5
30 -9
31 -9.5
32 -10
33 -10.5
34 -11
35 -11.5
36 -12
Code Gain (in dB)
00 -3
01 0 (Default)
02 3
Code Gain (in dB)
