45 Matrix VISIONPRO System Manual
Station is the software port number of the station from 00 to 07.
Default is 25mA
• To configure the same Loop Current for all stations at once, dial,
4116-*-Code
• To configure the Loop Length for a station, dial,
4117-1-Station-Code
Where,
Station is the software port number of the station from 00 to 07.
Default is Up to 5km (16404 ft.)
• To configure the same Loop Length for all stations at once, dial,
4117-*-Code
• To configure the Minimum Current for Off-hook Detection for a station, dial,
4118-1-Station-Code
Where,
Station is the software port number of the station from 00 to 07.
Default is 2 (12mA)
• To configure the same Minimum Current for Off-hook Detection for all stations at once, dial,
4118-*-Code
• To configure the On-hook Detection Current or lower for a station, dial,
4119-1-Station-Code
Where,
Station is the software port number of the station from 00 to 07.
Code Loop Current (in mA)
025
130
235
340
Code Loop Length
1 Up to 5km (16404 ft.)
2 Above 5km (16404 ft.)
Code
Minimum Current for Off-hook
Detection (in mA)
110
212
314
416
518
Code
On-hook Detection Current
or lower (in mA)
010
112
