63 Matrix VISIONPRO System Manual
Trunk is the software port from 0 to 2.
By default, code 0 is selected.
• To configure the same CO Termination for all trunks, dial,
3112-*-Code
• To configure the CO Line Type for a trunk, dial,
3113-1-Trunk-Code
Where,
Trunk is the software port from 0 to 2.
Code CO Termination
00 None
01
900 + 2.16 µF
02
600
03
1200
+ 376 + 112 nF
04
150
+ 510 + 47 nF
05
220
+ 820 + 150 nF
06
600
+ 1.5 µF
07
220
+ 120 + 115 nF
08
220
+ 820 + 115 nF
09
370
+ 620 + 310 nF
10
220
+ 820 + 120 nF
11
300
+ 1000 + 220 nF
12
270
+ 750 + 150 nF
13
200
+ 560 + 100 nF
Code CO Line Type
00 EIA-0
01 EIA-1
02 EIA-2
03 EIA-3
04 EIA-4
05 EIA-5
06 EIA-6
07 EIA-7
08 2000 ft. 22 awg
09 2000 ft. 24 awg
10 2000 ft. 26 awg
