Matrix VISIONPRO System Manual 78
By default, station group ‘00’ is assigned to all trunks during Day time as well as during Night time.
Exit SE mode.
Example:
Program the system for following requirements:
3 CO lines (S/w ports 0 to 2) are interfaced with VISIONPRO.
First two CO lines, CO1 and CO2 should land on station 21, 23, 25, 22 (S/w port 00, 02, 04, 01
respectively) during Day time. Rotation must be allowed.
CO1 and CO2 should ring on each station for 10 seconds. Station should ring in the given sequence only.
First two CO lines, CO1 and CO2 should land on station 21 (S/w ports 00) during Night time.
CO1 and CO2 should ring on station 21 continuously.
Third line should land on station 28 and 29 (S/w port 07 and 08 respectively) simultaneously during Day
time and Night time.
CO3 should ring continuously on both the stations.
Solution. Dial following commands in SE mode,
Make Group 0 as per the requirement:
4702-1-00-0-00 (to configure the station group)
4702-1-00-1-02
4702-1-00-2-04
4702-1-00-3-01
4703-1-00-0-10 (to configure the Ring Timer)
4703-1-00-1-10
4703-1-00-2-10
4703-1-00-3-10
4704-1-00-0-0 (to configure continuous or non-continuous ring)
4704-1-00-1-0
4704-1-00-2-0
4704-1-00-3-0
4705-1-00-1 (to configure the rotation method)
Make Group 1 as per the requirement:
4702-1-01-0-00 (to configure the station group having the same station)
4702-1-01-1-00
4702-1-01-2-00
4702-1-01-3-00
4703-1-01-0-10 (to configure the Ring Timer)
4703-1-01-1-10
4703-1-01-2-10
4703-1-01-3-10
4704-1-01-0-1 (to configure continuous or non-continuous ring)
4704-1-01-1-1
4704-1-01-2-1
4704-1-01-3-1
