Matrix Visionpro System Manual

79 Matrix VISIONPRO System Manual
4705-1-00-0 (to configure the rotation method)
Make Group 2 as per the requirement:
4702-1-02-0-07 (to configure the station group)
4702-1-02-1-08
4702-1-02-2-07
4702-1-02-3-08
4703-1-02-0-10 (to configure the Ring Timer)
4703-1-02-1-10
4703-1-02-2-10
4703-1-02-3-10
4704-1-02-0-1 (to configure continuous or non-continuous ring)
4704-1-02-1-1
4704-1-02-2-1
4704-1-02-3-1
4705-1-02-0 (to configure the rotation method)
3301-1-0-00 (to assign a station group as the Trunk Landing Group for a trunk during Day time)
3301-1-1-00
3301-1-2-02
3302-1-0-01 (to assign a station group as the Trunk Landing Group for a trunk during Night time)
3302-1-1-01
3302-1-2-02
By default, all the station groups contain first four stations. Hence, if less number of stations are to be
programmed in a station group then assign the same stations again for remaining destinations within the
group. As shown in the example above, station group 1 contains only one station i.e. station 21. Hence all
other destinations within a group are assigned the same station.
