SCREEN DEFINITIONS
www.maxcessintl.com
CYGNUS
MI 850A316 1 B
Page 54 of 66
Screen Function
Definition
System type
Select to enter the system type menu. From here you
may select either UNWIND, REWIND, or one of the four
point-to-point system configurations. See also Figure 3
Taper
Select to enter taper options screen. You may enter the
taper percent, full roll, and core diameters. Without a
separate diameter sensor, CYGNUS will make an
estimation of the current diameter of the roll based upon
the numbers entered here; see also TAPER___%
Taper ___%
When REWIND type is selected, you may enter a value
here that will taper off the output as the roll progresses
from core to full. This feature is useful for reducing the
inward forces that develop in rolls with a large
differential between core and full diameters. If you are
experiencing crushed cores, telescoping or starring rolls,
try increasing taper in steps until you reach a value that
works well for your process; see also TAPER,
DIAMETER
Tension alarm
Toggle to activate the web break detection feature. See
also DIGITAL OUTPUT MODE, TENSION ALARM
LEVEL ___ and TENSION ALARM DELAY ___
Tension alarm delay ___sec
Enter a value to set an amount of time the actual tension
must remain below the TENSION ALARM LEVEL ___%
before the web break alarm is activated. See also
TENSION ALARM. Values greater than 100% are given
a high tension alarm.
Tension alarm level ___%
Enter a value to determine when CYGNUS will send a
signal through TB3.4 & TB3.5 to indicate that a web
break has occurred. The value entered represents a
percentage of deviation below the tension SETPOINT.
See also TENSION ALARM. A “VALUE GREATER
THAN 100%” will provide a HIGH TENSION ALARM.
Tension decreases, clutch or motor
For point-to-point applications using a clutch or motor
and drive, select 5 if the controlled device is located
upstream from the sensor placement or 0 if it is
downstream from the sensor placement. See also
Figure 3
Tension increases, brake or regen drive
For point-to-point applications using a brake or
regenerative drive, select 3 if the braking device is
located upstream from the sensor placement or 8 if it is
downstream from the sensor placement. See also
Figure 3
Tension on / off
Toggles the output between 0% for OFF and under the
control of all other modes for ON. When TOGGLE
selected, TB4.7 also toggles.
Tension on/off mode
Toggle to indicate if TENSION ON/OFF will be triggered
from keypad (toggle) or TB4.7 (level).
