Maytag Chopper Dishwashers
GENERAL INFORMATION
Dishwasher Specifications
Line Voltage/Frequency : 120 VAC/60 Hz
Amps : 15A
Low Volts Power Supply : -5 VDC (REF), 13 VDC (+8V, -5V), Neutral (VCC)
Supply Water Flow Rate : To ll 2 qt (1.9 L) in 27 seconds, 120 psi maximum, 20 psi minimum
Supply Water Temperature : Minimum - 120° F (49° C)
Water Charge : 1.58 gal. (6.0 L) Approximate
Control : Electronic Control
Wash Motor : 120 VAC, Run Winding (3-7 W), Aux Winding (6-12 W)
Drain Motor : 120 VAC (15-60 W)
Fill Valve : 120 VAC, (890-1,090 W)
Heater : 120 VAC, (8-30 W)
Dispenser : Solenoid: 120 VAC, (260-300 W)
Wax Motor: 120 VAC, (1.4K-3.0K W)
AC Fan Motor : 120 VAC, (60-80 W) (some models)
DC Fan Motor : 5 VDC, (31K-41K W)
Vent Wax Motor : 120 VAC, (600-1,800 W)
Power Blast Wax Motor : 120 VAC, (600-1,800 W)
Sensors : NTC Thermistor
Water Sensor (OWI)
Switches : Door Switch (13 VDC)
Float Switch (120 VAC)
TCO/Bi-Metal : Incorporated into Control Board (Penninsula Slots)
Fuse : F9 = Small Triac Load Fuse
Wash System : Maintenance Free Hard Food Disposer
Lower Spray Arm Rotaon : 12 to 40 rpm
Upper Spray Arm Rotaon : 12 to 30 rpm
Filtraon : 4-Blade Stainless Steel Chopper
PowerBlast Available on all models
Depth : 24 3/4” (62.86 cm) without handles, 27 1/2” (69.85 cm) with handles
Height : 34 1/2” (87.63 cm) max., 33 1/2 (85.09 cm) min.
Width : 23 7/8” (60.64 cm)
Weight : 102 lbs. (46.27 kg)

Maytag MDB series Specifications

General

Type	Built-In
Capacity	14 Place Settings
Tub Material	Stainless Steel
Energy Star Certified	Yes
Soil Sensor	Yes
Heated Dry	Yes
Control Type	Electronic
Delay Start	Yes
