GENERAL INFORMATION
Maytag Chopper Dishwashers
n
1-9
Parts & Features
Figure 9
3
Parts and Features
BOTTOM RACK
TOP RACK
Upper level wash
Water feed tube
Model and serial number label
Water inlet opening
Detergent dispenser
Heating element
Upper spray arm
Silverware basket
(varies by model)
Cup shelf
(varies by model)
Overfill protection float
Lower spray arm has pressurized sprays
that provide effective cleaning.
Rinse aid dispenser reduces
spotting and improves drying.
Rack height adjusters
(on some models)
Fold down tines
(on some models)
High side shelf
(on some models)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Maytag MDB series and is the answer not in the manual?

Maytag MDB series Specifications

General IconGeneral
TypeBuilt-In
Capacity14 Place Settings
Tub MaterialStainless Steel
Energy Star CertifiedYes
Soil SensorYes
Heated DryYes
Control TypeElectronic
Delay StartYes
