GENERAL INFORMATION
Maytag Chopper Dishwashers
n
1-3
General Theory of Operation
Maytag Chopper Wash System
Maintenance Free Chopper System
A 4-Blade stainless steel chopper pulverizes food, prevenng
parcles from plugging the wash system and spray jets,
providing opmal cleaning without the need to prerinse
No more scraping plates. The 4-blade stainless steel chopper
disintegrates the food parcles that come o your dishes so
they don’t end up recirculang and scking to your dishes and
glassware.
How Chopper Works (See Figure 1)
1. Water and food parcles ow through the coarse lter
then are disintegrated by the Chopper blades (A).
2. An impeller pulls soiled water into the wash pump
through the screen (B), ltering soil parcles too large
to pass through and sending them back to the Chopper
blades.
3. The wash water is then cycled back through the spray
arms (C).
4. During the drain phase, a secondary pump ushes out
used wash water.
Figure 1 - Chopper Wash System
n Maytag® dishwashers feature the most
powerful motor on the market, so you
can be sure what you put in comes out
clean.
(A)
(B)
(C)

Maytag MDB series Specifications

General

Type	Built-In
Capacity	14 Place Settings
Tub Material	Stainless Steel
Energy Star Certified	Yes
Soil Sensor	Yes
Heated Dry	Yes
Control Type	Electronic
Delay Start	Yes
