Maytag MDB series User Manual

COMPONENT ACCESS
Maytag Chopper Dishwashers
n
4-5
Figure 3
5. Remove latch assembly from door, (see Figure 4).
6. Disconnect harness assembly.
Figure 4
Door Latch
Strike
Entry
Figure 4
Remove Door Latch Assembly
1. Unplug dishwasher or disconnect power.
2. Perform the procedures on page 4-4, “Remove Outer Door
Panel” prior to performing the following steps.
3. On some “early” models, it will be necessary to rst
remove the UI assembly to access the door latch assembly
(see Figure 1).
Remove UI
T-20 Screw
Figure 1
4. To remove door latch assembly, insert a small at-blade
screwdriver into the clip slots on each side of the latch.
Gently push in to release latch clips, (see Figures 2 and 3).
Figure 2
Removing Door Latch Assembly
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Front

Maytag MDB series Specifications

General

Type	Built-In
Capacity	14 Place Settings
Tub Material	Stainless Steel
Energy Star Certified	Yes
Soil Sensor	Yes
Heated Dry	Yes
Control Type	Electronic
Delay Start	Yes
