Meggitt vibro-meter VM600 Quick Start Manual

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600
Mk2
machinery protection system (MPS)
1-7
Installing a rack
INTRODUCTION TO THE VM600
Mk2
MACHINERY PROTECTION SYSTEM (MPS)
Rack-mounted Fan
Rack-mounted Fan
VM600
rack
(side view)
Rack-mounted Fan
Rack-mounted Fan
Front
of rack
VM600
rack
Case A
Case B
Airflow
Inclined plates
to deflect airflow
(for example:
PNR 957.15.01.1103)
(Side view)
Figure 1-3: Minimum required spacing above, below and between
VM600
Mk2
/VM600 system racks (ABE04x) in an enclosure using natural or forced ventilation
Natural ventilation Forced ventilation
Natural ventilation Forced ventilation
Front
of rack
>50 mm
>50 mm
>50 mm
>50 mm
>50 mm
>50 mm
>50 mm
>50 mm
Airflow
