Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600
Mk2
machinery protection system (MPS)
1-15
Installing VM600
Mk2
modules
INTRODUCTION TO THE VM600
Mk2
MACHINERY PROTECTION SYSTEM (MPS)
1.5.2 Installation restrictions
Table 1-1 show the installation restrictions that apply to MPS modules/cards in a
VM600
Mk2
/VM600 system rack (ABE04x).
Table 1-1: Attribution of slots in a VM600
Mk2
/VM600 system rack (ABE04x)
VME
slot no.
Module/card or system component
accepted in front module/card cage
Module/card or system component
accepted in rear module/card cage
00
CPU
Mk2
(Reserved for CPUx)
IOC
Mk2
(Reserved for IOCx)
01
(Reserved)
RLC16
Mk2
(RLC16 or IRC4)
02
03 to 14
MPC4
Mk2
(AMC8, MPC4 or XMx16)
IOC4
Mk2
or RLC16
Mk2
(IOC4T, IOC8T or XIO16T, or RLC16 or IRC4)
15
(Reserved for RPS6U as PS2
(Power supply 2, PS2)
(Width of RPS6U = 3 slots))
RLC16
Mk2
(RLC16 or IRC4)
16
RLC16
Mk2
(RLC16)
17
RLC16
Mk2
(RLC16)
18
(Reserved for RPS6U as PS1
(Power supply 1, PS1)
(Width of RPS6U = 3 slots))
RLC16
Mk2
(RLC16)
19
(Reserved for rear panel associated with the rack
power supply (one or two RPS6Us))
20
Notes
A MPC4
Mk2
module must have an IOC4
Mk2
module installed directly behind it in a VM600
Mk2
/VM600 rack.
In a VM600
Mk2
/VM600 system rack (ABE04x), one or two RPS6U rack power supplies can be installed. The rack
can have two RPS6U rack power supplies installed for different reasons: in order to support rack power supply
redundancy or in order to supply power to the modules/cards. Refer to a VM600 machinery protection system
(MPS) hardware manual for further information.
