Meggitt vibro-meter VM600 Quick Start Manual

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600
Mk2
machinery protection system (MPS)
2-11
MPC4
Mk2
machinery protection and condition monitoring module
OVERVIEW OF VM600
Mk2
MACHINERY PROTECTION SYSTEM (MPS) HARDWARE
For further information on the MPC4
Mk2
module firmware and operating modes,
see 4.1 MPC4
Mk2
module firmware and 4.2 MPC4
Mk2
module operating modes.
Table 2-3: Behaviour of MPC4
Mk2
module buttons
MPC4
Mk2
module buttons
Description
1 (left) 2 (right)
Power-up mode
X---
During the start of Power-up mode, press and hold button 1 for at
least 5 seconds to force module into Recovery mode
Operational mode
--- X
When Locked (safety/secure operating mode), press button 2
5 times within 5 seconds to switch Operational mode to Unlocked
(maintenance operating mode)
--- X
When Unlocked (maintenance operating mode), press and hold
button 2 for at least 1 second to switch Operational mode to Locked
(safety/secure operating mode)
XX
Press and hold both button 1 and button 2 for at least 2 seconds to
force module into Power-up mode
Fail-safe mode
--- X
For an “error” (displayed by VibroSight System Manager), press
and hold button 2 for 1 second to force module into
Operational mode
XX
For a “fatal error” (displayed by VibroSight System Manager), press
and hold both button 1 and button 2 for 2 seconds to force module
into Operational mode
Recovery mode
XX
Press and hold both button 1 and button 2 for at least 2 seconds to
force module into Operational mode
